TR-D02 Pure electric bakingheat shrink tube machine

Categories	Inserting Tube Machine and Heat Shrink Tube Baking Machine
Brand	Turing
Model	TR-D02
Power	AC220V/50HZ,
Application	heat shrinkable tube baking machine
Feature	Stable Performance
Warranty	1year
Control	Servo and Step motor
Contact	Lily 0086-13715588365
FOB port	shenzhen ,guangzhou ,zhongshan
Terms of Payment	Western Union, MoneyGram, T/T
Download
Update Time	Nov 21,2024

Contact Now

Favorites

Detail Information

TR-D02 Pure electric bakingheat shrink tube machine

Size & weight：H445*W240*D338mm,15kg

Heating temperature：0~450°

Heat Shrink Diameter:0-30mm

Heat Shrink Length:0-60mm

Heat Shrink Efficiency:450-900times/H

air output:580L/min (adjustable)

Air vents (optional):L-type/Y-type (L-type as standard)

Power source:220V 50Hz

Product Advantage

1, high-speed fan gas supply, do not want the air source, as long as the powersupply can be used, lightweight, easy to move;

2, the machinery can maintain a constant temperature, energy saving and effi-cient, and baking products blowing temperature will not drop too much;

3, the heating device using resistance wire heating, under normal circumstances isdifficult to burn out;

4, blowing nozzle can be customised according to product specifications, you canreplace the nozzle at will;

5, set up with infrared sensing and foot control two control modes, and can beswitched at any time;

6, there is a delay timer function, you can set the time of heat shrinkage, you canalso set the automatic cycle start;

7, compact structure, compact design, small size, can be placed in the productionline synchronous use;

8, double shell design, and the middle of the sandwich with high-temperature in-sulation cotton, so that the temperature of the outer shell will not overheat, notonly to make the working environment comfortable, but also to reduce energywaste.
