TR-SZ01 semi-automatic plug insert terminal crimping machine
TR-SZ01 semi-automatic plug insert terminal crimping machine
Detail Information
TR-SZ01 semi-automatic plug insert terminal crimping machine
power supply： 220V 50Hz
capacity： 800-1200pcs/H
size： 500x1050x1360mm
Mainboard Power：1.5KW
Closed height
adjustment: 10mm
power: Motor 1.1KW, Vibrating disc 120W
pneumatic: 0.4-0.8Pa
pressure capability: 4T(2T/3T/5T/6Toptional)
Slider Stroke: 300mm(40mm)
Closed stroke: 26mm
weight: Approx.180kg
Suitable for two- and three-plug internal racks with vibration plate rail feeding device seamlessly connected to the mould.
Product Features
1. PLC programme control, vibrating plate automatic sorting feeding, and sent to theriveting position, manual threading, step on the foot pedal, the equipment automaticallyriveted assembly of three pins reed.
2. Touch screen setting, easy to operate, simple maintenance, lack of material or faultautomatic alarm shutdown.
3.Processing speed: 800-1200pcs/H.
4. Detection mode: fibre optic amplifier, proximity magnetic switch automatic inductiondetection.
5.Working mode: automatic/manual/single station cycle.
