TR-201 Semi-automatic FFC Flexible Cable Terminal Crimping Machine

Panning accuracy：±0.01 mm

Applicable wire diameter：2-48 PIN (customisable)

environmental temperature：-5 to 40°C

separation distance：1.27-5.08 mm

power supply：AC 220V 50/60Hz

Crimping capacity：20 kN

power ：1000 W

Size & Weight：L800*W600*H1200 mm，100 kg

2. Applicable to some shaped flexible wire terminal crimping operations.

3. Support jump PIN crimping, interval fixed distance crimping.

4. Quickly store the parameter formula, and then call it with one key.

5. Compatible with a variety of PIN position line, fast switching

6. With alarm light, alarm stop and high light.

7. Servo motor with screw drive, high precision motion system

8.Independent research and development, hardware and software combination, easy to follow upgrading.

9. Equipment formula one-key storage, quick call, can display the current selection of the formula.

10.CNC interface, easy to learn and use.

11. Pressure detection system, MES interface and othercomponents can be added.

Functions: Cut to length, single/double end crimping, single/double end stripping

single end single wire through the rubber shell in sequence,single end through the sheath and pull it into place.
