TR-401 Copper Tube Mica tape wrapping machine flat wrap tape equipment

Equipment Model：TR-401

Operating Mode：Touch screen, foot pedal

Operating Mode：Full entanglement, point entanglement, multi-segment entanglement

Power Supply：AC110V~AC220V

Winding length：infinitely long

Winding wire diameter：3-40mm

Tape Material：PVC, acetate tape (without isolation paper), flannel, etc

Winding Maximum Efficiency：12R/S

Tape Specifications：Inside 4 38mm, outside s  140mm, width s 20mm (if there are other tape size.can be customized according to the requirements of the tape fixing frame)

Pneumatic：24P

Operation mode: touch screen, foot switch

Working mode: full wrapping, point wrapping, multi-stage wrapping

Power supply: AC210V～AC240V

Air pressure: ≥4P

Wrapping length: unlimited

Winding combined wire diameter: 1MM-30MM (can be customized if it is larger than 30)

Tape specifications: inner ￠38MM, outer ≤￠110MM, width ≤19MM (if there are other tape sizes, the tape holder can be customized as required)

Type of tape: PVC/flannel/acetate tape (no release paper), etc.

Operating temperature: 0-45°

Operating humidity: 10-90%RH (no condensation)

Cooling method: natural wind

Maximum winding frequency: 12R/S
